Technical Specification
- Pure sine wave inverter with a maximum input power of 9kW for the 6kW model, 12kW for the 8kW model, 15kW for the 10kW model, and 18kW for the 12kW model.
- MPPT charge controller feature.
- Bi-directional inverter that can rapidly charge the external batteries.
SS-6kW-LLKS-HYB-3P-IP65-01 / SS-8kW-LLKS-HYB-3P-IP65-02
SS-10kW-LLKS-HYB-3P-IP65-03 / SS-12kW-LLKS-HYB-3P-IP65-04
| Model | SS-6kW-LLKS-HYB-3P-IP65-01 | SS-8kW-LLKS-HYB-3P-IP65-02 | SS-10kW-LLKS-HYB-3P-IP65-03 | SS-12kW-LLKS-HYB-3P-IP65-04 |
|---|---|---|---|---|
| Battery Input Parameters | ||||
| Supported Battery Type | LiFePO4 or Lead-Acid | |||
| Battery Input Voltage Range | 40~60V | |||
| Max. Charge Voltage | 60V (Configurable) | |||
| Max. Charge Current | 120A (Configurable) | 150A (Configurable) | 180A (Configurable) | 220A (Configurable) |
| Max. Discharge Current | 130A (Configurable) | 180A (Configurable) | 220A (Configurable) | 260A (Configurable) |
| Battery Capacity (Recommended) | 100~2000Ah | |||
| Charge for LiFePO4 Battery Pack | Communicating with BMS of the Battery Pack | |||
| PV String Input Parameters | ||||
| Max. DC Input Power | 9000W | 12000W | 15000W | 18000W |
| DC Input Voltage | 800V | |||
| MPPT Voltage Range | 200~650V | |||
| Start-Up Voltage | 180V | |||
| Max. Input Current | 18A x 2 = 36A (2 MPPT Channels) | 23A x 2 = 46A (2 MPPT Channels) | 28A x 2 = 56A (2 MPPT Channels) | |
| AC Output Parameters (Back-Up)(Feed to Essential Load) | ||||
| Max. Output Power | 6000W | 8000W | 10000W | 12000W |
| Max. Output Apparent Power | 6000VA | 8000VA | 10000VA | 12000VA |
| Peak Output Apparent Power | 12000VA | 16000VA | 20000VA | 24000VA |
| Max. Output Current (Each of Three-Phase) | 16A | 18A | 23A | 25A |
| Nominal Output Voltage | 3L/N/PE 220V/380V 3L/N/PE 230V/400V | |||
| Nominal Output Frequency | 50/60Hz (+/-0.2%) (Configurable) | |||
| Max. Bypass Current | 40A | 42A | 63A | |
| Shift Time (Bypass and Inverter) | 10ms | |||
| Output THDv (Resistor Load) | <3% | |||
| AC Input Parameter (On-Grid)(Bypass to Essential Load & Charge the Battery/Feed to Home Load) | ||||
| Max. Input Power (Bypass to Essential Load/ Charge the Battery) | 6000W | 8000W | 10000W | 12000W |
| Max. Output Power (Feed to Home Load) | 6000W | 8000W | 10000W | 12000W |
| Max. Apparent Input Power (Bypass to Essential Load/ Charge the Battery) | 6000VA | 8000VA | 10000VA | 12000VA |
| Max. Apparent Output Power (Feed to Home Load) | 6000VA | 8000VA | 10000VA | 12000VA |
| Nominal Input/Output Voltage | 3L/N/PE 220V/380V 3L/N/PE 230V/400V | |||
| Nominal Input/Output Frequency | 50/60Hz (Auto Adjusted to Fit Home Grid) | |||
| Max. Bypass Current | 40A | 42A | 63A | |
| Shift Time (Bypass and Inverter) | 10ms | |||
| Efficiency | ||||
| Max. Efficiency | 97.6% | |||
| Max. Battery to Load Efficiency | 94.0% | |||
| Europe Efficiency | 97.6% | |||
| MPPT Efficiency | 99.9% | |||
| Protection | ||||
| Integrated | Battery Over-Charge Protection, Battery Low-Voltage Protection, Over-Temperature Protection, Output Overload Protection, Output Short Circuit Protection, Output Over-Voltage Protection | |||
| Compliances | ||||
| EMC/Safety Regulation | This product complies with ISO and its relevant norms and standards. Approvals and certifications are subject to change without notice. Please verify current status with Sunsynk before ordering. | |||
| General Information | ||||
| Operating Temperature Range | -20ºC ~ +50ºC (>35ºC Derating) | |||
| Protection Degree | IP65 | |||
| Warranty | See website for Warranty details | |||
| Dimension | 550x585x280mm | 620x585x280mm | ||
| Weight | 35kg | 42kg | ||
